Deep groove ball bearings 6213-2Z/C3
SKU:BEA000546
Deep groove ball bearings 6213-2Z/C3
Manufacturer : SKF
Description
Technical specification
DIMENSIONS
| d |
65 mm
|
|
|---|---|---|
| D |
120 mm
|
|
| B |
23 mm
|
|
| d1 |
≈ 83.3 mm
|
|
| D2 |
≈ 105.8 mm
|
|
| r1,2 |
min. 1.5 mm
|
ABUTMENT DIMENSIONS
| da |
min. 74 mm
|
|
|---|---|---|
| da |
max. 83.2 mm
|
|
| Da |
max. 111 mm
|
|
| ra |
max. 1.5 mm
|
CALCULATION DATA
| Basic dynamic load rating | C |
58.5 kN
|
|---|---|---|
| Basic static load rating | C0 |
40.5 kN
|
| Fatigue load limit | Pu |
1.73 kN
|
| Reference speed |
12 000 r/min
|
|
| Limiting speed |
6 000 r/min
|
|
| Calculation factor | kr |
0.025
|
| Calculation factor | f0 |
14.7
|
MASS
| Mass bearing |
1.06 kg
|
|---|
